Description
Thông số kỹ thuật
| 700MHz | 900MHz | 1800MHz | 2100MHz | ||
|---|---|---|---|---|---|
| Frequency Band (MHz) | 703-788 | 890-960 | 1710-1880 | 1920-2170 | |
| Port 1*6ports max | Port1*6ports max | Port1*6ports max | Port1*6ports max | ||
| Insertion Loss | 8.5dB max | ||||
| V.S.W.R | 1.35 max | ||||
| Isolation | Inter Bands | 50dB | |||
| In band | 22dB min | ||||
| Impedance | 50Ω All ports | ||||
| Passive Intermodulation | -150dBc CW 2×43 dBm | ||||
| Average Maximum Power | 40W max. per input port | ||||
| Operating Temperature | -10 to + 50°C | ||||
| Storage Temperature | -20 to + 60°C | ||||
| Relative Humidity | 0~95% non-condensing | ||||
| RoHS Applicant | Complied | ||||
| Dimensions | 482.6 X 360 X 265.9 (Width x Depth x Height) | ||||
| Weight | (30kg) | ||||
| Connector | All ports :4.3-10 –Female (Mini DIN connector) | ||||
| Mounting Type | 19inch rack mounted | ||||
| Color | Beige | ||||
