Dual Band Combiner 2300-2600Mhz/3400-3600MHz

Twin Diplexer Combiner 2300-2600Mhz/3400-3600MHz

Quadruplexer Combiner is consist of 4 dual duplexer that shares 2 frequencies

The product covers with WCS 2300, IMT 2600 and TDD3600 for LTE/5G System. It is equipped 2 output ports and 4 input ports and waterproof function

This document defines objective specification for a family of 2305-2673MHz / 3400-3600MHz

The purpose of the Product is to combine or separate two frequency bands into or out from a common feeder cable

Cellular outdoor

Description

Frequency : 2305~2673MHz/3400~3600MHz
PIMD : -160 dBc (3rd order with 2x20W)
Impedance: 50 Ω All ports
DC pass
Waterproofing Class : IP67
RoHS Applicant :Complied
RF Connector :4.3-10-Female
No of port : Single unit 4 input and 2 output ports, Dual unit 8 input and 4 output ports
